The Acromion Locking Plate is a pre-contoured fixation device engineered for surgical treatment of scapular acromion fractures and osteotomies. It is an integral part of the 2.7 mm locking plate system, offering rigid stability and anatomical conformity to the shoulder girdle.

Plate Design & Geometry

• Available in Left and Right side-specific configurations
• 9-Hole plates: 79 mm in length
• 10-Hole plates: 72 mm in length
• Thickness: 1.5 mm (low-profile)
• Angled locking holes (~20°) enhance fixation in the thin cortical bone of the acromion
• No intraoperative bending required due to pre-contoured design

Material & Surface Treatment

• Manufactured from AISI 316L Stainless Steel (ISO 5832-1) or Ti-6Al-4V ELI Titanium Alloy (ISO 5832-3)
• Stainless steel variant is electropolished to reduce soft tissue irritation
• Titanium variant is anodized for improved identification and biocompatibility

Clinical Applications

• Acromion fractures (post-traumatic or post-operative)
• Os acromiale repair or nonunion fixation
• Acromial base osteotomies following reverse shoulder arthroplasty

Instrumentation & Compatibility

• Compatible with AO-style 2.7 mm locking instruments
• Supports 2.7 mm locking and cortical screws
• Used with targeting arms, torque-limited drivers, and 2.0 mm drill bits

Regulatory Compliance

• Manufactured in ISO 13485-certified facilities
• CE Marked for global regulatory approval
• Each implant is batch-labeled and fully traceable
